Project ID

For seismic datasets the ProjectID can contain a NDR9 code as an attribute for new projects, for existing projects which already have a NDR9 code, it can be selected as part of the ProjectID creation process.

The identification code of a project will be defined by an alphanumeric character code where the format of the characters is defined as: CCCCYYYYtypeNNNN and detailed below:

Project ID: CCCCYYYYtypeNNNN definition
CCCC	4 character alphanumeric code for company - See company code list, for 2 character companies append trailing underscores to make it 4 characters, e.g BP__ or WOS_ or WSOC
YYYY	4 character numeric year in which project was performed (if between years, choose earliest), this is not the acquisition year of the input datasets
Type	4 lower case character code defining the type of project– e.g. well, seis
NNNN	4 character numeric project designator, right justified, padded with zeros

The “type” four lower case character code defines the type of project as follows:

Code	Types of project per code
well	Wellbore projects - All pre and post drill data, including drilling reports, digital well log, joined well logs, log images, vsp data, checkshot, reports etc.
seis	Seismic projects - Acquisition, processing or reprocessing projects. This includes all types of acquisition (e.g. 2d,3d,4d) and all data types, supporting information and reports etc.
mhaz	Near surface high resolution site survey projects - shallow investigation seismic, shallow boreholes, acoustic, sonar, bathymetry surveys, shallow hazard reports. All data types, supporting information and reports etc.
rems	Remote sensing, potential and diffusive field projects - CSEM surveys, stand alone gravity and/or magnetic surveys, Lidar, satellite observations. All data types, supporting information and reports etc.
intp	Remote sensing, potential and diffusive field projects - CSEM surveys, stand alone gravity and/or magnetic surveys, Lidar, satellite observations. All data types, supporting information and reports etc.

The NNNN four character number will be a sequence number as each project from the same company in the same year for the same project type is loaded.

0001	first project from company EG in year 2007
0002	second project from company EG in year 2007

Example of ProjectID names

Acquisiton ProjectID examples
EG__2016seis0001	first seismic 2D survey, company EG in year 2016
EG__2016seis0002	second seismic 3D survey, company EG in year 2016
EG__2019seis0001	first seismic 3D survey, company EG in year 2019
EG__2019mhaz0002	second Site investigation survey, company EG in year 2019
EG__2019mhaz0003	second Site investigation survey, company EG in year 2019
BZC_2017rems0001	first 3D CSEM survey, company BZC in year 2017
BQ__2018well0001	first wellbore logging project, company BQ in year 2018
BQ__2018well0001	first stand alone borehole seismic, company BQ in year 2018

Projects are independently named and do not refer to other projects as part of the ProjectID. The creation of the ProjectID can include metadata to show what the related datasets that form part of this project, this may include other ProjectID’s.

Processing and reprocessing ProjectID examples
Example project	ProjectID	Comment
2020 CCS potential study	GWG_2020intp0001	ProjectID metadata can mention multiple input datasets
2009 Acquisition survey	GWG_2009seis0002	none
2009 Processing project	GWG_2009seis0003	ProjectID metadata can mention GWG_2009seis002 as input dataset
2012 Acquisition survey	AVC_2012seis0001	none
2012 Processing project	AVC_2012seis0002	ProjectID metadata can mention AVC_2012seis001 as input dataset
2014 Reprocessing project	GWG_2014seis0002	ProjectID metadata can mention GWG_2009seis002 as input dataset
2016 merge processing project	BR__2016seis0003	ProjectID metadata can mention GWG_2009seis002 and AVC_2012seis001 as input datasets
